Resp-Aer-Meter Scientific

Resp-Aer-Meter
The Resp-Aer-Meter Scientific offers a wide range of additional information and data and can be used for scientific applications, for example in the medical field

Besides the detection of a potential superspreader, the Resp-Aer-Meter Scientific offers access to a wide range of other measurement data, such as number of particles, size and size distribution, time course, measurement times, and much more. In addition, many parameters, such as the measurement duration or limit values can be set individually.

工作原理
优势

具体的益处

  • 所谓"超级传播者"可通过检测其呼出气体中的高浓度颗粒物在 30 秒内被识别
  • 该技术可快速区分高传染性与低传染性的新冠病毒携带者
  • 可对呼出空气中的气溶胶浓度与粒径进行测量
  • 检测粒径范围覆盖 145 纳米至 10 微米
  • 尤其在约 145 纳米至 1 微米的病毒特征粒径范围内具备超高分辨率
  • 测量结果可立即评估并生成记录文档
应用领域

为各行业提供定制化解决方案

  • Medical-scientific research, to answer questions such as
    • Do infectious respiratory diseases differ by exhaled particle size distribution?
    • Is an increased particle concentration in the breath due to a specific particle size range?
    • How do disease variations or personal characteristics (age, BMI, previous diseases...) influence the outcome?
您有其他问题吗?
请随时与我们联系。
技术数据

详细信息

测量原理
Optical light-scattering
测量范围 (数量浓度)
0 – 20,000 particles/cm³
测量范围 (粒径)
0.15 – 10 µm
体积流量
9.5 l/min
User interface
Touchscreen, 800 • 480 pixel, 7" (17.78 cm)
Data acquisition
Digital, 20 MHz processor, 256 raw data channels
Power consumption
Approx. 200 W
下载

关于Resp-Aer-Meter Scientific的更多信息

Brief Description

Brief product description in two-pages as PDF


Product Description

Detailed product description as PDF
