Cloud Droplet Analyzer

High-resolution, stationary aerosol spectrometer for the measurement of cloud aerosols.

The Cloud Droplet Analyzer is an optical aerosol spectrometer for high-resolution measurement of the size distribution and number concentration of cloud aerosols.

工作原理
优势

您的特定益处

  • Continuous and simultaneous measurement of particle number concentration and particle size distribution
  • Intuitive and simple operation
  • Remote monitoring, operation and maintenance easily possible
  • No radioactive material
  • No consumables
  • Low energy consumption
  • Low maintenance
  • On-site calibration possible
应用

针对众多行业的个性化解决方案

  • Cloud research
  • Ice nucleation events
  • Environmental research
您有其他问题吗?
请随时与我们联系。
技术数据

详细信息

Measuring principle
Optical light scattering at single particles
Reported data
Particle size distribution, particle number concentration, mean volume diameter, equivalent diameter, water content
Measurement range (number C_N)
0 – 200 particles/cm3
Measurement range (size)
0.6–40 µm, 0.8–100 µm
Volume flow
5 l/min
Size channels
64 (32/decade)
Time resolution
1 s–24 h
Interfaces
USB, 以太网(局域网), RS-232/485
User interface
Touchscreen, 800 • 480 pixel, 7" (17.78 cm)
Protocols
UIDEP, UDP, ASCII, MODBUS
Software
PDAnalyze
Data acquisition
Digital, 20 MHz processor, 256 raw data channels
Light source
Long term stable LED
Housing
防护等级IP55的防水外壳
Operating system
Windows 10 IoT Enterprise
Power supply
115–230 V, 50/60 Hz
Installation conditions
-30–+40 °C, <95% rH, non-condensing, max. 4.000 m (above sea level)
Sampling head
Sigma-2被动收集器,可加热并自动调节
Dimensions
约 1,150 • 742 • 404 mm (H x W x D)
Weight
Approx. 40 kg
Noise emission
< 60 dB(A)
Power consumption
正常运行:约60 W,最大200 W
