Promo® 2000 P

With automatic regulation of the sampling flow through the welas® aerosol sensors at an overpressure up to 10 bar
Depending on the aerosol composition to be measured, i.e., the carrier gas component and the particle material, pressure changes in the carrier gas can significantly influence the particle size distribution, e.g., due to condensation or evaporation.

For this reason, the welas ® aerosol sensors welas ® 2070 P, 2100 P, 2200 P, 2300 P and welas ® 2500 P are equipped with a pressure-tight cuvette to ensure isobaric and isothermal sampling into the sensor's measurement volume.


The Promo®system is usually calibrated for the operating volume flow. As the operating volume flow changes with pressure, it is advantageous for the user if automatic volume flow regulation for the sampling volume flow is provided for in the device.

In the Promo® 2000 P , the pressure of the carrier gas is measured, and the required operating volume flow is automatically set to 5 l/min.

Includes:

  • Mass flow controller for volume flow regulation
  • Absolute pressure capsule
  • Filter unit to protect the flow rate control

工作原理
优势

您的特定益处

  • Measuring range of 0.2 to 100 µm (up to 4 measuring ranges selectable in one device)
  • Up to four measuring ranges in only one device:
    • 0,2 µm – 10 µm
    • 0,3 µm – 17 µm
    • 0,6 µm – 40 µm
    • 2 µm – 100 µm (additionally for sensors 2300 and 2500)
  • Up to 128 size channels per measuring range
  • Concentration range of 1 particle/cm3 to 106 particles/cm3
  • Calibration curves for different refractive indices
  • Very high and reproducible counting efficiency rate starting at 0.2 µm
  • Pressure-resistant up to 10 bar (optional)
  • Optical fibre technology
  • Simple operation with a large touch display
  • Calibration, cleaning and lamp replacement can all be performed independently by the customer
  • External control by RS 232 or Ethernet
  • With analysis software PDAnalyze
  • Optional: Software PDControl for operation as welas® digital available
  • Low maintenance
  • Reliable function
  • Reduces your operating expenses
应用

针对众多行业的个性化解决方案

  • Emission monitoring of installations
  • Control of grinding and classification processes
  • Monitoring of production processes in the food, pharmaceuticals and chemicals industries
  • Testing of complete filters, inertial and wet separators or electrostatic precipitators
您有其他问题吗?
请随时与我们联系。
技术数据

详细信息

Measuring principle
Optical light-scattering
Measurement range (number C_N)
< 1 • 106 Partikel/cm3
Measurement range (size)
0.2 – 10 µm, 0.3 – 17 µm, 0.6 – 40 µm, 2 – 100 µm
Volume flow
5 l/min regulated by mass flow
Size channels
Max. 128 (64/decade)
Interfaces
USB, Ethernet (LAN), Wi-Fi, RS-232/485
User interface
Touchscreen, 800 • 480 pixel, 7" (17.78 cm)
Data logger storage
4 GB Compact Flash
Software
PDControl, FTControl, PDAnalyze
Data acquisition
Digital, 20 MHz processor, 256 raw data channels
Light source
Xenon arc lamp 35 W
Housing
Table housing, optional: with mounting brackets for rack-mounting
Support options
Direct remote access, Palas webserver service
Operating system
Windows embedded
Power consumption
100 W
Installation conditions
+5 – +40 °C (control unit)
Dimensions
185 • 450 • 315 mm (H • W • D) (19")
Weight
Control unit: approx. 8 kg, sensor: approx. 2.8 kg
